Crown CDi 2-600 Analog input 2 channel 600W per output channel 4 Ohm or 100V Line
search
  • Crown CDi 2-600 Analog input 2 channel 600W per output channel 4 Ohm or 100V Line
  • Crown CDi 2-600 Analog input 2 channel 600W per output channel 4 Ohm or 100V Line

Crown CDi 2-600BL with BLU LINK Analog input 2 channel 600W per output channel 4 Ohm or 100V Line

£2,052.00
Tax included
£1,710.00 Tax excl.

Crown CDi 2-600BL with BLU LINK

Analog input 2 channel

600W per output channel

4 Ohm or 100V Line Output

Quantity

Ask a Quote
Crown CDi 2-600 with BLU LINK Analog input 2 channel 600W per output channel 4 Ohm or 100V Line

The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost.  Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 2|600 offers streamlined functionality to work in almost any medium sized installation such as cinema, houses of worship, bars, lounges, and more.  Designed for ease-of-use in a variety of applications, the 2|600 is a 2-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer.  The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.

Feature Comparison

CDi DriveCore Model Channels Network Control DSP Control Port BLU link
2|300 2
2|300BL 2
4|300 4
4|300BL 4
2|600 2
2|600BL 2
4|600 4
4|600BL 4
2|1200 2
2|1200BL 2
4|1200 4
4|1200BL 4



Output Power: Dual Mode - All Channels Driven

CDi DriveCore Model Channels 2Ω 4Ω 8Ω 16Ω 70Vrms 100Vrms
2|300 / 2|300BL 2 150W 300W 300W 150W 300W 300W
4|300 / 4|300BL 4 150W 300W 300W 150W 300W 300W
2|600 / 2|600BL 2 300W 600W 600W 300W 600W 600W
4|600 / 4|600BL 4 300W 600W 600W 300W 600W 600W
2|1200 / 2|1200BL 2 850W 1200W 1200W 600W 1200W 1200W
4|1200 / 4|1200BL 4 850W 1200W 1200W 600W 1200W  1200W

Minimum Guaranteed Power (1kHz, all channels driven, max distortion 0.5%, duration 0.5 seconds, 120 - 240Vrms - 50/60Hz)



Output Power: Bridge Mono Mode - All Channels Driven

CDi DriveCore Model 4Ω 8Ω 16Ω 140Vrms 200Vrms
2|300 / 2|300BL 300W 600W 600W 600W 600W
4|300 / 4|300BL 300W 600W 600W 600W 600W
2|600 / 2|600BL 600W 1200W 1200W 1200W 1200W
4|600 / 4|600BL 600W 1200W 1200W 1200W 1200W
2|1200 / 2|1200BL 1200W 2400W 2400W 2400W 2400W
4|1200 / 4|1200BL 1200W 2400W 2400W 2400W 2400W

Minimum Guaranteed Power (1kHz, all channels driven, max distortion 0.5%, duration 0.5 seconds, 120 - 240Vrms - 50/60Hz)

Recommended for: Installed Sound.

Features

DriveCore Technology – Crown’s proprietary DriveCore technology eliminates hundreds of components within each amplifier, reducing the variability of component values, increasing reliability, resulting in incredible audio fidelity from an efficient design.

Network Control and Monitoring – Through Harman’s HiQnet Audio Architect software, the CDi DriveCore can be controlled, configured, and monitored through standard TCP/IQ network.

DSP – On-board Digital Signal Processor in each amplifier allows for custom configuration

  • Input Router
  • Input Delay – Up to 1000ms
  • Input Parametric EQ – 8 band
  • Crossover
  • Output Parametric EQ – 8 band
  • Output Delay – Up to 100ms
  • LevelMAX™ Limiter

BLU link (BL models only) – Both receive and send channels over HARMAN’s 256 channel, fault-tolerant audio BUS, BLU link

Direct Drive 70/100Vrms Output – Each output channel is capable of provide either 70V or 100V for high impedance applications.

Front-Panel Interface – Completely configure the amplifier using an intuitive front-panel interface.

GPIO/AUX Port – Recall presets, mute channels, monitor faults, power on/off the amplifier, and more through a combined GPIO/AUX Port.

CRO0341

Data sheet

Product Category Feature
Sound
Price Unit
Each
Condition
new
Availability
available for order
Brand
Crown
Manufacturer
Crown
Colour
Black
Number of Input Channels
2 Channel
Number of Output Channels
2 Channel
Wattage per Channel (W)
600W
Output Line Voltage
Low Impedance and 100V Line Outputs
Total Power Wattage (W)
1200
Product Rack Height
2U
IP Network Connectivity
Yes
On-board DSP
Yes
BLU LINK Connection
Yes

Specific References

EAN13
3423523591881
