Mode ECO-MCP-55 LCD Control Plate - Black (10 Black Buttons, Twin Gang, excluding Fascia Plate)
Mode ECO-MCP-55 LCD Control Plate - Black (10 Black Buttons, Twin Gang, excluding Fascia Plate)
Key Features
» Single gang plate
» Screwless fascias plate utilising the MK Aspect range
Mode ECO-MCP-55 LCD Control Plate - Black (10 Black Buttons, Twin Gang, excluding Fascia Plate)
Key Features
» Single gang plate
» Screwless fascias plate utilising the MK Aspect range
» Buttons available in either black or white
» Multifunction buttons - scene recall, impulse and toggle
» Indicator LED’s with seven user selectable RGB colours and intensity. Red, Green, Blue, Magenta, Cyan, Orange and White.
» Integral IR Infrared receiver
» 1-4 Room Partition facility
» Two volt-free contact switch inputs - Individually addressable and configurable
» Keypad Lockout
» Fault condition feedback via LED flashing
» 2 year warranty
The lighting within an installation can be manually controlled by a multi-button Control Plate.
The 10 Button Control Plate provides eight configurable buttons allowing scene recall, impulse and toggle and two multifunction buttons providing On & Raise and Off & Lower with integral IR receiver. All buttons have integral RGB LED’s.
The indicator LED’s within the buttons are RGB and dimmable, therefore seven colours of selectable intensity are available. Where buttons have a multifunction i.e. Toggle On & Off, the LED colour can toggle, say Green & Red to provide current status.
ECO-MLP-55BK
Data sheet
- Condition
- new
- Availability
- preorder
Specific References
- EAN13
- 3412431728045
