RGB or RGBW LED DMX Kinetic Pixel Tube 2m Pendant with 2 Motorised Winchs 0-1.5m or 0-4m and Colour Tube 0.2m per sec DMX512 8CH

RGB or RGBW LED DMX Kinetic Pixel Tube 1m Pendant with 2 Motorised Winchs 0-1.5m or 0-4m and Colour Tube 0.2m per sec DMX512 8CH

- 8 DMX512 channels
- Power: 60W
- Lifting Speed 0.2m/sec
- Customisable lifting height:
0-1.5m or  0-4m available
cost comes with 2pc motorised lifting set and 1 led tube







RGB LED DMX Kinetic Pixel Tube 1m Pendant with 2 Motorised Winchs 0-1.5m or 0-4m and Colour Tube 0.2m per sec DMX512 8CH






Kinetic LED Tube in Line (2 hoists + 1 tube)
Tube length: 1000mm or 2000mm
Lifting cable length: 2m, 4m or customized.

2 Pixel Tubes:
The LEDs in every tube are halved into two sections.
Each half is controlled by the hoist at its end.
8 DMX control channel (each hoist)

32 Pixel Tubes:
The LEDs in every tube are preprogramed as 32 Pixels of RGBW 128 Controll Channels of DMX
8 DMX control channel for each hoist and LED Pixels are controlled seperately from the hoist on a seperate 4 Pin Connection on the hoists.


IP rating: IP23 (Optional IP54)
SMD5050 RGB 3-in-1 LEDs,
60 pcs per meter
AC90V～240V 50～60Hz,
100W (2 hoists + 1 tube)
Max. lifting speed: 0.25m/sec.
0-100% linear dimmer, flicker free.
Strobe effects
Ta: 5℃～45℃
Max. payload (single hoist): 2kg
Lifting cable length: 2m, 4m or customized.
Net Weight (single 2m hoist): 6.4kg;
Gross Weight: 7 .6kg
Packing size (single 2m hoist)：46×37.5×24cm
Net Weight (single 1000mm tube): 0.8kg
Net Weight (single 2000mm tube): 1.6kg
